HDMI input to Composite Video and Audio Output Converter

  • Details

  • Recommended

  • Reviews

  • Send

Details

Item Number
HDCOM
Item Condition
New
Price
£19.00 (inc VAT £22.80)

Options

Quantity


  • Diecast Box 115 x 64 x 26mm

    Diecast Box 115 x 64 x 26mm

    High Quality, Heavy Duty Diecast Aluminium Box

    Easy to drill for switches and sockets etc. For housing & screening electronic circuits. M3 Fixing screws Dims: 115 x 64 x 26mm



    G106
    £6.25
  • Pair of HD Baluns for CCTV

    Pair of HD Baluns for CCTV

    A Pair of CCTV HD Baluns

    Send & Receive Signals via CAT5 / CAT6 / CAT7 Cable.

    RJ45 Sockets on both items

    Can be used with both HD and older techniques, between cameras & DVRs.

    price per pair

    BU2H
    £2.85
  • Balun Pair for HD CCTV - Video Audio & Power

    Balun Pair for HD CCTV - Video Audio & Power

    A pair of CCTV Baluns with Audio

    Send & Receive Video, Power & Audio via CAT5 / CAT6 / CAT7 Cable

    RJ45 sockets on both items

    Can be used with both HD and older techniques, between cameras & DVRs.

    price per pair

    BU3H
    £4.85
  • 2.1 x 5.5mm DC Line Plug with Screw Terminal Block

    2.1 x 5.5mm DC Line Plug with Screw Terminal Block

    DC Line Plug 2.1 x 5.5mm with 2 way screw terminal block connection Marked + and -

    RXP
    £0.75
  • 2.1 x 5.5mm DC Line Socket with Screw Terminal Block

    2.1 x 5.5mm DC Line Socket with Screw Terminal Block

    DC Line Socket (Female) 2.1 x 5.5mm with 2 way screw terminal block connection Marked + and -

    Accepts 2.1 x 5.5mm Plugs.

    RXL
    £0.75
  • 12V DC 2A Adaptor Power Supply

    12V DC 2A Adaptor Power Supply

    Switchmode Plug in type (Regulated) Power Supply. 12VDC (Single voltage) 2A max. 5.5 x 2.1mm (Centre Positive) plug on the output. Fits most CCTV System Cameras etc

    BSM1220
    £10.75
  • 9 to 24Volt 24 Watt High Efficiency Power Supply 7 Voltages & UK Mains Plug

    9 to 24Volt 24 Watt High Efficiency Power Supply 7 Voltages & UK Mains Plug

    9Volt to 24Volt 24Watt HIGH EFFICIENCY POWER SUPPLY with 7 Voltages & UK Mains Plug



    Regulated Voltages Selected by Small Rotary Switch:

    Voltages: 9V, 12V, 13.5V, 15V, 18V, 20V & 24V

    12 V     2Amps

    13.5V   1.77Amps

    15 V     1.6Amps

    18 V     1.33Amps

    20 V     1.2Amps

    24 V     1Amp

    Multi input voltages: Can operate from 100VAC to 240VAC 50/60Hz



    6 Different Adaptor plugs



    BV924
    £16.95
  • High Defintion HD 4 Channel 1080P DVR With Easy Mobile Viewing & Cloud Technology

    High Defintion HD 4 Channel 1080P DVR With Easy Mobile Viewing & Cloud Technology

    High Definition 1080P HD 4 Channel Real-time AHD DVR Audio on One Channel

    With this latest Quiet Operating Fanless 4 Channel DVR you can record either AHD Cameras (1.0MP up to 2.0MP) at stunning High Definition.
    Will playback all 4 cameras at the same time (split screen or single screen) unlike other inferior HD   Price includes 1TB Hard Drive, upgradable to 6TB.
    Can work on some old analogue cameras

    Features:
    Easy Web & Mobile Set up
    1 Hard Drive: up to 6TB
    1 Audio Channel
    Mobile/Laptop/PC/Smartphone viewing.
    Advanced H.264 High Profile Compression
    Strong processing capacity: Up to 4 Channels AHD 1080N @ 25fps recording and playback synchronously
    Dual stream encoding for high quality recording and streaming on all broadband speeds.
    Built-in IE plug ins, or powerful CMS software included.
    Multiplex operation: Preview, recording, playback, backup, network live, mobile phone view.
    All operations are independent of each other.
    Playback mode Normal , Fast speed Playback, Manual and Single-Frame
    Simple backup via USB stick, external HDD or via network / Internet.
    Alarm alerts via email.
    Auto power recovery, returning to the pre-power-down state
    Complete with Mouse and IR remote

    Technical Data:
    Industrial grade micro controller chip Huawei HIS chipset Hi3521
    Linux Operating system
    Simple to use GUI interface mouse operation
    Channel modes: Display & Screen Displays 1/4
    TV System: PAL
    Image encoding: H.264 (High Profile)
    Live quality: VGA and HDMI - 4x1080P
    Playback Quality: 4x1080N AHD Simultaneously or 1080P IP
    AHD mode: 4x1080N
    Analogue mode: 4x960H
    NVR mode: 4x1080P
    Mixed Mode: (2x1080N AHD + 2x960H Analogue) or (2x1080N AHD + 2x1080P IP)
    Video Motion Detection: Each channel can be set to 192 multiple detection areas.
    Video input: 4 BNC sockets
    Video output: 1 VGA & 1 HDMI
    Audio input: 1 Phono (RCA)
    Audio output: 1 Phono (RCA) & HDMI
    3G, WIFI extension via USB port
    Tour: Yes
    Power Supply: 12V 2A Included
    Dimension 260(W) x 221(D) x 44mm(H)

    Approximate Hard Drive Recording Times

    4 cameras at 1080N real-time

    1TB:             2 weeks
    2TB:             4 weeks
    4TB:             8 weeks
    6TB:             12 weeks

    4 cameras at 960H real-time

    1TB:             4 weeks
    2TB:             8 weeks
    4TB:             16 weeks
    6TB:             24 weeks
    HX4T
    £85.00
  • High Definition HD 8 Channel 1080P DVR With Easy Mobile Viewing & Cloud Technology

    High Definition HD 8 Channel 1080P DVR With Easy Mobile Viewing & Cloud Technology

    High Definition 1080P HD 8 Channel Real-time AHD DVR Audio on one Channel.

    Quiet Operating Fanless 8 Channel DVR will record AHD Cameras (1.0MP up to 2.4MP) & IP cameras at stunning High Definition.
    Playback on all 8 cameras at the same time (split screen or single screen)
    Price includes 1TB Hard Drive, upgradable to 6TB
    Can work on some old analogue cameras

    Features:
    Easy Web & Mobile Set up
    1 Hard Drives up to 6TB
    1 Audio input
    Mobile/Laptop/PC/Smartphone viewing.
    Advanced H.264 High Profile Compression
    Strong processing capacity: Up to 8 Channels AHD 1080N @ 25fps recording and playback synchronously
    Dual stream encoding for high quality recording on all broadband speeds.
    Built-in IE plug ins, or powerfull CMS software included.
    Multiplex operation: Preview, recording, playback, backup, network live, mobile phone view.
    All operations are independent of each other.
    Playback mode Normal , Fast speed Playback, Manual and Single-Frame
    Simple backup via USB stick, external HDD or via network / Internet.
    Alarm alerts via email.
    Auto power recovery, returning to the pre-power-down state
    Complete with Mouse and remote

    Technical Data:
    Industrial grade micro controller chip Huawei HIS chipset Hi3521
    Linux Operating system
    Simple to use GUI interface mouse operation
    Channel modes: Display & Screen Displays 1/4/8(3x3 with 1 data screen)
    TV System: PAL
    Image encoding: H.264 (High Profile)
    Live quality: VGA and HDMI - 8x1080P
    Playback Quality: 8x1080N AHD Simultaneously or 1080P IP
    AHD mode: 8x1080N
    Analogue mode: 8x960H
    NVR mode: 8x1080P
    Mixed Mode: Any Paired combination of HD and standard Cameras or (4x1080N AHD + 4x1080P IP)
    Video Motion Detection: Each channel can be set to 192 multiple detection areas.
    Video input: 8 BNC sockets
    Video output: 1 VGA & 1 HDMI
    Audio input: 4 Phono (RCA)
    Audio output: 1 Phono (RCA) & HDMI
    3G, WIFI extension via USB port
    Tour: Yes
    Power Supply: 12V 2A Included
    Dimension 260(W) x 221(D) x 44mm(H)

    Approximate Hard Drive Recording Times

    8 cameras at 1080N real-time

    1TB:             1 weeks
    2TB:             2 weeks
    4TB:             4 weeks
    6TB:             6 weeks

    8 cameras at 960H real-time

    1TB:             2 weeks
    2TB:             4 weeks
    4TB:             8 weeks
    6TB:             12 weeks
    HX8T
    £105.00

Product Rating

Sign in to rate

Customer Reviews

There have been no reviews for this product.

Login to post a review

Send to Friend

: *
: *
: *
Type the characters you see in the picture:


*

HDMI input to Composite Video and Audio (Phono RCA) Output Converter

This HDMI to AV unit converts HDMI video & audio to standard AV composite video & stereo audio.

Works  on 720P or 1080P HDMI into PAL (UK) & NTSC (American) in either 480i or 576i.

Ideal for connecting modern HD equipment like CCTV DVRs, BlueRay Players, SkyHD Boxes to old SD (standard definition) inc TVs,VHS VCRs,DVD recorders etc.

USB powered , so can be powered from the device you are converting.



Resolutions Supported

640x480@60Hz,800x600@60Hz,1024x768@60Hz,1280x720@60Hz,1280x1024@60Hz,
1360x768@60Hz, 1600x1200@60Hz,1920x1080@60Hz,480i/60Hz,480p/60Hz,576i/60Hz,
576p/60Hz,720p50/60Hz,1080I50/60Hz,1080p/60Hz.
CVBS output:PAL,NTSC_M,and NTSC_J

Package Contents:
HDMI converter
Manual
USB cable
